| Model Parameters |
| Name |
C2C (Mini O Plus) |
C2C (Mini O) |
| Model |
CS-CV206-C0-3B2WFR |
CS-CV206-C0-1A1WFR |
| Camera |
| Image Sensor |
1/2.7’’2MP HD progressive scan CMOS |
1/4‘’ 1MP HD progressive scan CMOS |
| Shutter Speed |
Self-adaptive shutter |
Self-adaptive shutter |
| Lens |
2.8mm@F2.0, Horizontal angle: 115°, Diagonal angle: 135° |
2.8mm@F2.5, Horizontal angle: 90°, Diagonal angle: 111° |
| Lens Mount |
M12 |
M12 |
| Day & Night |
IR-cut filter with auto-switching |
IR-cut filter with auto-switching |
| DNR |
3D DNR |
3D DNR |
| WDR |
Digital WDR |
Digital WDR |
| Compression |
| Video Compression |
H.264 |
H.264 |
| H.264 Type |
Main profile |
Main profile |
| Video Bit Rate |
HD, balanced and smooth bit rate |
HD, balanced and smooth bit rate |
| Image |
| Max. Resolution |
1920×1080 |
1280×720 |
| Image setting |
Brightness, contrast, saturation, etc. (configurable via EZVIZ Studio) |
Brightness, contrast, saturation, etc. (configurable via EZVIZ Studio) |
| BLC |
Support |
Support |
| Network |
| Storage |
Support Micro SD card (Max. 256G) |
Support Micro SD card (Max. 256G) |
| Smart Alarm |
Motion detection |
Motion detection |
| Wi-Fi Pairing |
SmartConfig (Wi-Fi One-Key Configuration)/AP paring |
SmartConfig (Wi-Fi One-Key Configuration)/AP paring |
| Protocol |
EZVIZ cloud proprietary protocol |
EZVIZ cloud proprietary protocol |
| Interface Protocol |
EZVIZ cloud proprietary protocol |
EZVIZ cloud proprietary protocol |
| General Features |
Anti-Flicker, Dual-Stream, Heartbeat Messages, Mirror Image, Password Protection, Watermark |
Anti-Flicker, Dual-Stream, Heartbeat Messages, Mirror Image, Password Protection, Watermark |
| Minimum Network Requirements |
2Mbps |
1Mbps |
| Wi-Fi |
| Standard |
IEEE802.11b, 802.11g, 802.11n |
IEEE802.11b, 802.11g, 802.11n |
| Frequency Range |
2.4 GHz ~ 2.4835 GHz |
2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth |
Supports 20MHz |
Supports 20MHz |
| Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate |
11b: 11 Mbps, 11g: 54 Mbps, 11n: 150 Mbps |
11b: 11 Mbps, 11g: 54 Mbps, 11n: 150 Mbps |
| General |
| Operating Conditions |
-10ºC ~ 50ºC (14°F ~ 122°F), Humidity 95% or less (non-condensing) |
-10ºC ~ 50ºC (14°F ~ 122°F), Humidity 95% or less (non-condensing) |
| Power Supply |
DC 5V±10% |
DC 5V±10% |
| Power Consumption |
Max. 3W |
Max. 3W |
| IR Range |
Max. 7.5 meters |
Max. 7.5 meters |
| Product Dimensions |
128mm x 58mm x 38mm |
128mm x 58mm x 38mm |
| Packaging Dimensions |
149mm x 87.5mm x 91.5mm |
149mm x 87.5mm x 91.5mm |
| Weight |
120g |
120g |
